Specification
| TYPE | DESCRIPTION |
| Mfr | Texas Instruments |
| Series | - |
| Package | Tape & Reel (TR) |
| Product Status | ACTIVE |
| Features | Load Discharge, Slew Rate Controlled |
| Package / Case | 8-WDFN Exposed Pad |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | On/Off |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | High Side |
| Rds On (Typ) | 4.4mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 2.5V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | 0.8V ~ 5.5V |
| Current - Output (Max) | 6A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | 8-WSON (3x3) |
Transport
Shipping fee
Shipping starts at $40, but can be over $40 for some countries. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
Basic shipping charges (package ≤0.5kg or corresponding volume) depend on time zone and country.
Mailing method
Currently, our products are shipped via DHL, FedEx, SF and UPS.
Delivery time
Once the goods are shipped, the estimated delivery time depends on the shipping method you choose:
FedEx International, 5-7 business days.
The following are logistics times for some common countries.
